20-100mm Aluminum Foil Lid Plastic Jar Sealing Heat Machine Handheld Induction Bottle Foil Sealer Metal Metallurgy Machinery

20-100mm Aluminum Foil Lid Plastic Jar Sealing Heat Machine Handheld Induction Bottle Foil Sealer Metal Metallurgy Machinery

aluminum foil lid sealing machine

handheld induction bottle foil sealer

plastic jar sealing heat machine

Plaats van herkomst:

China

Merknaam:

YUYANG

Certificering:

CE

Modelnummer:

YYSQ-TC-60AB (driefasig)

Neem contact met ons op
Verzoek om een Citaat
Productgegevens
Werkkracht:
340V-430V
Maximale ingangsstroom:
90A
Uitgangsvermogen:
60 kW
Fluctuerende frequentie:
5-20 KHz
De stroomsnelheid van koelwater:
0,08-0,16 MPa 12 l/min
beschermingspunt voor de watertemperatuur:
50c
Productgrootte:
belangrijkste: 808*530*1260 MM transformator: 840*420*740 MM
Netto Gewicht :
hoofd: 102kg transformator: 78kg
Uitgangsstroom:
400-4500A
Markeren:

aluminum foil lid sealing machine

,

handheld induction bottle foil sealer

,

plastic jar sealing heat machine

Betaling en verzendvoorwaarden
Min. bestelaantal
1 Instellen
Prijs
$2000
Verpakking Details
multiplex doos
Levertijd
5-10 werkdagen
Betalingscondities
T/T, L/C, Western Union
Levering vermogen
200 sets per maand
Productbeschrijving
20-100mm Aluminum Foil Lid Plastic Jar Sealing Heat Machine
Handheld Induction Bottle Foil Sealer for Metal Metallurgy Machinery
Product Characteristics
  • Advanced IGBT inverting device with automatic frequency tracking
  • High-frequency heating with rapid operation - consumes only 20-30% of power compared to electronic tube induction heating
  • Secure voltage operation for reliable and safe performance
  • Manual and automatic regulation with comprehensive protection against over voltage, over current, water shortage, phase failure, and overheating
  • No open flame, noise, or pollution - environmentally friendly and fire-safe operation
  • Recommended applications: Brazing, welding, forging, hot cooperation, melting, quenching, and annealing
Advanced Features
This High Frequency Induction Heating Machine incorporates the most advanced electrical components and unique techniques for rapid, localized metal heating. It can penetrate non-metal materials to heat metals until fusion occurs without direct contact, providing safe, economical, and pollution-free technical solutions.
Key Advantages
  • Portable Design: Integrated construction saves over 80% space and 75% weight compared to traditional transformers, offering superior flexibility with monolithic shell design resistant to weak acids and alkalis
  • Complex Metal Heating: Hand-held machine head uses amorphous magnetic core material for wider frequency range, providing superior heating effects for irregular shaped workpieces
  • Efficient Operation: Rapid heating within 8 seconds, ideal for air conditioning and refrigerator industry copper pipe welding, transformer welding, and other complex applications with stable magnetic field output
Technical Parameters
ModelYYSQ-TC-60AB (Three phase)
Work Power340V-430V
Maximum Input Current90A
Output Power60KW
Fluctuating Frequency5-20KHZ
Output Current400-4500A
Cooling Water Flow Rate0.08-0.16Mpa 12L/Min
Water Temperature Protection50°C
Main Unit Dimensions808×530×1260mm
Transformer Dimensions840×420×740mm
Main Unit Net Weight102kg
Transformer Net Weight78kg
Industrial Applications
  • Brazing Materials: Copper and brass brazing, tungsten steel and stainless steel brazing, iron and copper brazing, aluminum and copper brazing
  • Glasses welding, fishing tool welding, hardware appliances welding
  • Carbide saw and saw-tooth welding, carbide blade welding
  • Jewelry and watches welding
  • Electronic Industry: Motor rotor hot-cooperation, electrode silver soldering and tin soldering
  • Metal implants, bulbs fight electrode
  • Band accessory soldering, golf head, pipe welding
  • Communication equipment soldering, copper coaxial cable connector soldering
