Name: Laboratory Needle Flame Tester Needle Flame Tester for Insulation Material Fire Testing
Brand: DONGGUAN YUYANG INSTRUMENT CO., LTD
SKU: JJ F056
Price: 1660.00 USD
Availability: InStock

Huis > Producten > Brandbaarheid het Testen Materiaal >

Laboratory Needle Flame Tester Needle Flame Tester for Insulation Material Fire Testing

Needle Flame Tester for Insulation

Flammability Testing Equipment Fire Test

Needle Flame Tester Laboratory Use

Plaats van herkomst:

China

Merknaam:

YUYANG

Certificering:

Modelnummer:

JJ F056

Neem contact met ons op

Verzoek om een Citaat

Laboratory Needle Flame Tester Needle Flame Tester for Insulation Material Fire Testing

Productgegevens

Bunsenlamp:

Buisdiameter: 9,5 mm ± 0,1 mm

Test de hellingshoek van de lamp:

0°, 45°, 90°, snelle positionering; Maximale reis ca. 150 mm

Testgas:

98% methaan (referentiegas); of aardgas van 37MJ/m³ ±1MJ/m³

Ontstekings- en verwijderingstijd:

1s ~ 999,9s (digitale preset beschikbaar)

Vlamhoudtijd:

1s ~ 999,9s (digitaal display, niet vooraf ingesteld)

Herhaalde ontstekingscycli:

1 ~ 9999 keer (digitale preset beschikbaar)

Voeding:

0,5 kVA, 220 V, 50-60 Hz

Markeren:

Needle Flame Tester for Insulation

Flammability Testing Equipment Fire Test

Needle Flame Tester Laboratory Use

Betaling en verzendvoorwaarden

Min. bestelaantal

1 set

Prijs

$1620-1700

Verpakking Details

Multiplex doos

Levertijd

7-30 dagen

Betalingscondities

L/C, D/A, D/P, T/T, Western Union

Levering vermogen

200 sets per maand

Verwante producten

Horizontal and Vertical Flammability Tester PV 3357 UL Standard Automotive Interior Material Burning Test Equipment

Vind de beste prijs

IEC60695-11-5 Needle Flame Tester HT-5169T-N Lab Flammability Testing Equipment for Electrical Appliance Safety Test

Vind de beste prijs

Plastic Horizontal Burning Rate Test Apparatus ASTM D635 UL94 Plastic Flammability Testing Equipment

Vind de beste prijs

Ul94 Horizontal Vertical Burning Combustion Testing Machine Flame Test Chamber Flammability Tester for Plastic

Vind de beste prijs

Neem contact met ons op

8613265296009

sales13@yuyangtest.com

86-769-26622869

Contact opnemen

Productbeschrijving

Laboratory Needle Flame Tester for Insulation Material Fire Testing The Laboratory Needle Flame Tester is a precision instrument designed to evaluate the flammability resistance of insulation materials and other solid electrical components. By applying a small, controlled needle flame to the test specimen, this apparatus determines the material's ability to resist ignition and self-extinguish, providing reliable data for fire safety assessment and quality control in
